357370
Feature | Feature Value |
---|---|
Forbindelsesteknologi | Ledningsført |
Værtsgrænseflade | USB |
Grænseflade | WLAN |
USB version | 2.0 |
Maksimal dataoverførselshastighed | 633 Mbit/s |
Netværksstandarder | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x |
Wi-Fi | Ja |
Wi-Fi-bånd | Dual-band (2,4 GHz / 5 GHz) |
Frekvensområde | 2,4 – 5 GHz |
Bedste Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Wi-Fi-standarder | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Understøttede WLAN-dataoverførselshastigheder | 11,54,150,200,433 Mbit/s |
Modulation | 16-QAM, 64-QAM, 256-QAM, CCK, COFDM, DBPSK, DQPSK, OFDM |
Sikkerhedsalgoritmer | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK |
Båndbredde (første) | 2,4 GHz |
Båndbredde (anden) | 5 GHz |
Intern | Ingen |
Produktfarve | Sort |
Antenne | Ja |
Antennedesign | Intern |
Modtager, følsomhed | 5GHz: 11a 6Mbps: -90dBm 11a 54Mbps: -73dBm 11n HT20 MCS0: -89dBm 11n HT20 MCS7: -70dBm 11n HT40 MCS0: -86dBm 11n HT40 MCS7: -67dBm 11ac VHT80 MCS0: -82dBm 11ac VHT80 MCS9: -56dBm 2.4GHz: 11b 1Mbps: -96dBm 11b 11Mbps: -88dBm 11g 6Mbps: -89dBm 11g 54Mbps: -74dBm 11n HT20 MCS0: -89dBm 11n HT20 MCS7: -72dBm 11n HT40 MCS0: -86dBm 11n HT40 MCS7: -66dBm |
Certificering | CE, FCC |
USB-drevet | Ja |
Understøttede Windows-operativsystemer | Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP |
Understøttede Mac-operativsystemer | macOS |
Understøttede Linux-operativsystemer | Ja |
Driftstemperatur (T-T) | 0 – 40 °C |
Opbevaringstemperatur (T-T) | -40 – 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 – 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 5 – 90% |
Bæredygtighedscertifikater | RoHS |
Bredde | 15 mm |
Dybde | 7,1 mm |
Højde | 18,6 mm |
Antal | 1 |
Pakkebredde | 138 mm |
Pakkedybde | 128 mm |
Pakkehøjde | 30 mm |
Pakkevægt | 90 g |
Hurtig installationsvejledning | Ja |
Overfører strømområde | 20 – 20 dBmW |
